HR-25KWT Automatic High frequency PVC welding machine
| Model： | HR-25KWT |
| Scope Of Application： | For PVC inflatable bed forming, air matress welding, bed cushion sealing |
| Features： | Most apply for APET,PETG,GAG etc Eco-friendly blister packing,tooth brush packing,soft line plastic box making,all material which need welding and cutting simultaneously,all can work by this machine. |
HR-25KWT Automatic High frequency PVC welding machine
Feature of machine:
1. Most apply for APET,PETG,GAG etc Eco-friendly blister packing,tooth brush packing,soft line plastic box making,all material which need welding and cutting simultaneously,all can work by this machine.
2. Double-direction automatic slipway,come-and-go or continuous delivering the mould,accurate-orientation, error + 20 um.3. Adjustable cutting pressure 1-50 tons,stable and realible in output,firm in structure.
3.Adopting high sensitive anti-sparkle device NL5557 to avoid damaging the mould efficiency.
Excellence of High frequency PVC welding machine for inflatable bed forming:
1.Spark suppressor: When sparks, the special electronic circuit works and cuts off the high frequency to suppress spark automatically and minimize the damage of electrodes and materials. Also. The warning lights works.
2.Prevention for radio interference device: Equipped with frequency stabilizer and high-frequency magnetic leakage suppressor. This device eliminates the leakage of radio waves to interfere other electronic devices such as TV, radios, etc..
3.Safety devices: When the current exceeds the limit value, the overload current relay works to protect oscillator and rectifier automatically. Frequency deviation caused by the improper operation is also prevented.
4.Easily adjustable device: Output power can be adjusted according to electrode size and material thickness. Other control devices and special electronic circuits can reduce required welding time and improve the machine's productivity.
You can see our website for more product information, please don't hesitate to call.
Technical parameter:
| Model | HR-25KW |
| Power | 25000W |
| Voltage | 380V 50/60HZ or customize |
| Frequency | 13.56MHZ |
| Input power | 35KVA |
| Rectifier | SILICON DIODE |
| Oscillation tube | 8T25RA |
| Max pressure | 1000kg |
| Operation mode | Pneumatic |
| Max distance of electrodes | 100MM |
| Moving distance of active horn | 100MM |
| Size of upper electrode | 800*1000mm |
| Size of lowwer electrode | 1000*1400mm |
| The range of tempreture | 30~200 oC adjustable |
| Welding time | 0~10S Adjustable |
