Rotary Table Auto Gluing Machine for cylinder bottom and lid, 8 stations.

Model：	HY-200
Scope Of Application：	PVC cylinder box, APET cylinder box (glue not white or frog after gluing). PETG cylinder box
Features：	Able to be operated by one woker, PLC and precision splitter makes the rotary table work exactly and stably.Speed: 900 - 1000 pcs / hour

Rotary Table Auto Gluing Machine for cylinder bottom and lid, 8 stations.

This machine HY-200 is able to glue bottom / lid to cylinders automatically :

worker feed products---glue apply --- bottom / lid gluing --- worker pick up finished products--next cycle.

Features:

Able to be operated by one woker,

PLC and precision splitter makes the rotary table work exactly and stably.

Speed: 900 - 1000 pcs / hour

Application:
PVC cylinder box, APET cylinder box (glue not white or frog after gluing).PETG cylinder box

Specification:

Diameters of cylinder: 40-200mm (need to change moulds)
Film thickness: 0.15-0.6mm
Compressed air : 0.6Mpa 350L/min
Power request: 220VAC(3 phases )2KW
Machine size: 900*1300*1750MM(L*W*H)
Glue speed: 800-1000 / hour
Accuracy: ≤±0.001MM
Weith: 480Kg

Apply for: PVC,APET, PETG
